Engine
Type
Displacement
Max. Power
Max. Torque
Air-cooled, 4-stroke single cylinder, OHC
97.2 cc
5.5 Kw (7.5 Ps) at 8000 rpm
7.95 Nm at 5000 rpm
Transmission & Chassis
Cluch
Gear box
Chassis Type
Multi-plate wet
4 Speed constant mesh
Tubular double cradle frame
Suspension
Front Rear
Telescopic hydraulic shock absorbers
Swing arm with hydraulic shock absorber
Brakes
Front Brake
Rear Brake Drum
Internal expanding shoe type (130 mm) type
Wheels & Tyres
Rim Size Front
Rim Size Rear
Tyre Size Front
Tyre Size Rear
18 x 1.60, Alloy /spoke wheel
18 x 1.60, Alloy / spoke wheel
2.75 x 18 – 42 P / 4 PR
2.75 x 18 – 48 P / 6 PR
Electricals
Battery
Head Light
12V-2.5 Ah
35W / 35W – Halogen bulb ( Multi – reflector type )
Dimensions
Length
Width
Height
Wheelbase
Saddle Height
Ground Clearance
Fuel Tank Capacity
Reserve
Kerb Weight
1970 mm
720 mm
1040 mm
1230 mm
785 mm
7.95 159mm
11 ltrs ( Min)
1 ltrs ( Usable reserve )
109 kg
Colors
