Engine
Type
Displacement
Maximum Power
Maximum Torque
Compression Ratio
Starting
Ingnition
Air-cooled, 4-stroke single cylinder OHC
97.2 cc
5.74 KW (7.8 Pc) @ 7500 rpm
8.04 N-m @ 4500 RPM
9.0 : 1
Kick start / Self start
Digital CDI
Transmission & Chassis
Cluch
Gear box
Chassis Type
Multi-plate wet
4 Speed constant mesh
Tubular double cradle frame
Suspension
Front
Rear
Telescopic hydraulic shock absorbers
Swing arm with 5 step adjustable hydraulic shock absorber
Brakes
Front break
Rear Brake Drum
Internal expanding shoe type (130 mm) type
Wheel and Tyres
Rim Size Front
Rim Size Rear
Tyre Size Front
Tyre Size Rear
18 x 1.60, Spoke wheel / Cast wheel
2.75 x 18 – 42 P / 4 PR, Unidirectional tyre
2.75 x 18 – 48 P / 6 PR, Unidirectional tyre
Electricals
Battery Head Light
MF battery, 12V 3Ah (Kick), 12 V4 Ah (Self)
12V 35W / 35W – Halogen bulb ( Multi – reflector type )
Dimensions
Length
Width
Height
Ground Clearance
Fuel Tank Capacity
Kerb Weight
1970 mm
720 mm
1040 mm
159mm
11 ltrs (Min).
109 kg, (Kick), 112 kg (Self)
Colors
