Engine
Type
Displacement
Maximum Power
Maximum Torque
Ignition
Air cooled, 4- stroke single cylinder OHC , Self start
149.2cc
9.7 kW (13.2 Ps) @ 7500 rpm
13.4 N-m @ 5000 rpm
D.C - CDI Ignition System
Transmission & Chassis
Gear box
5 Speed constant mesh
Suspension
Front
Rear
Telescopic Hydraulic Shock Absorbers
Swing Arm with Mono Suspension with Nitrox
Brakes
Front break
Rear Brake Drum
Dia 240 mm Disc
Internal expanding shoe type (110 mm)
Wheel and Tyres
Tyre Size Front
Tyre Size Rear
90 / 90 x 19 - 52 P
110 / 90 x 17 - 60 P
Electricals
Battery Head Light
Tail Stop Lamp
Turn Signal Lamp
12 V - 4 Ah, MF Battery
12 V - 35 W / 35 W - Halogen Bulb (Multi -Reflector Type)
12V - 0.5 W / 4.1 W LED Lamp
12 V - 10 W (Amber Bulb) x 4 nos (Multi-Reflector-Clear Lens)
Dimensions
Wheelbase
Ground Clearance
Fuel Tank Capacity
1360mm
245 mm
11.1 Litre (Min) - 2.6 Litre (Usable Reserve)
Colors
