Engine
Type
Displacement
Max. Power
Max. Torque
Bore x Stroke
Carburettor
Compression Ratio
Starting
Ingnition
Air-cooled, 4-stroke single cylinder OHC
97.2 cc
5.74 KW (7.8 Ps) at 7500 rpm
N-m
50.0 x 49.5mm
Side draft, variable venturi type
9.0 : 1
Kick start / Self start
DC - Digital CDI
Transmission & Chassis
Cluch
Gear box
Chassis Type
Multi-plate wet
4 Speed constant mesh
Tubular double cradle frame
Suspension
Front Rear
Telescopic hydraulic shock absorbers
Swing arm with adjustable hydraulic shock absorber
Brakes
Front Brake
Rear Brake Drum
Internal expanding shoe type (130 mm)
Internal expanding shoe type (110 mm)
Wheels & Tyres
Rim Size Front
Rim Size Rear
Tyre Size Front
Tyre Size Rear
18 x 1.6 Spoke wheel / Cast wheel
2.75 x 18 – 4 PR / 42 P
2.75 x 18 – 6 PR / 48 P
Electricals
Battery
Head Light
Tail Stop Lamp
Turn Signal Lamp
12V 3Ah
12V-35W/Halogen bulb, Trapezoidal, MFR
12V – 5 / 21 W, MFR
12V – 10W (Amber bulb) x 4 nos, MFR, clear lens
Dimensions
Length
Width
Height
Wheelbase
Saddle Height
Ground Clearance
Fuel Tank Capacity
Reserve
Kerb Weight
Minimum Turning
1965 mm
720 mm
1095 mm
1235 mm
785 mm
160 mm
9.5Ltrs
1.8 Ltrs
109 kg, (Kick), 112 Kg (Self)
2.10 mtrs.
Colors
