Engine
Type
Displacement
Max. Power
Max. Torque
Bore x Stroke
Carburettor
Starting
Ingnition
Air cooled, 4 - stroke single cylinder OHC
149.2 cc
10.6 kW (14.4 PO@ 8500 rpm)
12.80 N m @ 6500 rpm
57.3 x 57.8 mm
CV type with carburetor controlled variable ignition
Self Start
AMI - Advanced Microprocessor Ignition Sy
Transmission & Chassis
Clutch
Gear box
Chassis Type
Multiplate wet
5 Speed constant mesh
Tabular, diamond type
Suspension
Front
Rear
Telescopic hydraulic type
Rectuglar swing arm with 5 step adjustab gas reservior suspension
Brakes
Front Brake
Rear Brake Disc
Rear Brake Drum
Disc Dia 240 mm
Disc Dia 220 mm
Drum internal expanding shoe type (130 mm)
Wheels & Tyres
Rim Size Front
Rim Size Rear
Tyre Size Front
Tyre Size Rear
18 x 1.85, 5 Spoke cast wheel
18 x 2.15, 5 Spoke cast wheel
80 / 100 x 18 – 47 P
100 / 90 x 18 – 56 P
Electricals
Battery
Head Light
Tail Stop Lamp
Turn Signal Lamp
12 V -4 Ah, MF battery
12 V -35 WI 35W - Halogen bulb – Trapeze
12 V -0.5 WI 4.1W (LED lamps - Clear lens)
12 V -21 W (Amber bulb) x 4 nos. (MFR - CI)
Dimensions
LengthLight
Width
Height
Wheelbase
Ground Clearance
Fuel Tank Capacity
Reserve
Kerb Weight
2080mm
765mm
1145mm
1325 mm
145 mm
12.1 litre (Min)
1.5 litre (Usable reserve)
148 kg (Brakes - FR/ RR --> Disc/ Drum)
Colors
